Digital gas monitoring
No. Name Description Range Default
60 ADTxA
Analogue drive transmit message,
sensor A (top) CAN network
0-255 0
61 AMinA
Analogue drive. Minimum percent of
scale for zero output. Sensor A
0-100 3
62 AMaxA
Analogue drive. Maximum percent of
scale for full scale output. Sensor A
0-100 100
63 ADRxA
Receive message code to control local
analogue output. Sensor A
0-255 0
64 ADTxB
Analogue drive transmit message,
sensor B (bottom) CAN network
0-255 0
65 AMinB
Analogue drive. Minimum percent of
scale for zero output. Sensor B
0-255 3
66 AMaxB
Analogue drive. Maximum percent of
scale for full scale output. Sensor B
0-100 100
67 ADRxB
Receive message code to control local
Analogue output B
0-255 0
68 Baud
Baud rate for CAN network
Maximum network wire length is 1500
feet at rate 0 and 3000 feet at rate 1
Use rate 0 with model 5000
0-1 0
69 Man
Manual override from home screen
activates alarms 1, 1+2, 1+2+3. See
section 4.1
1-3 1
70 BDI
BACnet device instance
Enter part 1 (1000 to 4,194,303)
Press right arrow
Enter part 2 (0 to 999)
0-4,194,
303
60,000
+BMA
71 Light
1 = backlight always on
0 = on when keyboard activated
0-1 0
72
°C/°F
Display 0 = degrees C, 1 = degrees F
Will also convert settings 51 and 55
0-1 0
73 Cycle
Automatic cycle timer Alarm 1
00C = total Cycle time in minutes
Press right arrow
00R = Run time in minutes
0-255 00/00
74 Age
Sensor module A age in days
Press right arrow to display Sensor B
0
4.4 List of Settings Continued
General settings
