AR...24-3 Actuators, On/Off, Floating Point
Dimensions
3.46"
[88]
A
CAUTION Equipment damage!
Actuators may be connected in parallel.
Power consumption and input impedance must be observed.
For end position indication, interlock control, etc.,
ARB24-3-S incorporates one built-in auxiliary switches:
1 x SPDT, 3A (0.5A) @250 VAC, UL listed, adjustable 0° to 95°.
Actuators may also be powered by 24 VDC.
Meets cULus or UL and CSA requirements without the
need of an electrical ground connection.
W ARNIN G L IVE Electrical C omponents !
During installation, testing, servicing and troubleshooting of this product, it may
be necessary to work with live electrical components. Have a qualified licensed electrician
or other individual who has been properly trained in handling live electrical components
perform these tasks. Failure to follow all electrical safety precautions when exposed to live
electrical components could result in death or serious injury.
8.5" [216]
3.3"
[84]
2.49"
[63.4]
1.35"
[35]
C
B
2
3
4
Auxiliary switch
ARB24-3-S
0° to 95°
NO
NC
3
S1
S2
S3
Floating Point or On/Off control
ARB24-3
1 0
The indication of direction
is valid for switch position 1.
Blk (1) Common –
Red (2) +
Wht (3) +
Line
Volts
4
2
24 VAC Transformer
On/Off control
ARB24-3
1 0
The indication of direction
is valid for switch position 1.
Wht (3) +
a
a open
a closed
Blk (1) Common –
Red (2) +
Line
Volts
4
2
24 VAC Transformer
Wiring Diagrams
O50905 - 05/12 - Subject to change. © Belimo Aircontrols (USA), Inc.
W410
W411
W409
Valve
Nominal Top
Flange Face-to-Face
Body
Pipe Flange
Diameter Length
Height
Size Design
F05
A
7.50" [190.5]
8.00" [203.2]
5.50" [139.7]
6.60" [167.6]
C
8.10" [205.4]
8.40" [213.1]
B6250
B6300
2½" [65]
3" [80]
B6400
4" [100]
9.00" [228.6]
8.30" [210.8]
9.30" [235.9]
