Belimo EXT-CF230-D202-AF - Installation Guide; Mounting Method Steps

LCD Electronic Thermostat
EXT-CF230-D202-AF, EXT-CF230-D402-AF
RSA - A mais completa em soluções para HVAC e Automação
Avenida Ragueb Chohfi, 960 - Torre 3, Sala 73 - Jardim Três Marias, São Paulo-SP, Cep: 08375-000
Telefone Sac: 55 11 2031 6658 - Email: contato@rsistemasdeautomacao.com.br
Site: http://www.rsistemas-automacao.com.br
Installation Manual
Mounting Method
1
open the clip with screw driver
2
unplug the connector
3
wiring
4
mount it with screws
5
plug in the connector
6
close it with clip
O56002 - 04/12 - Subject to change. © Belimo Aircontrols (USA), Inc.
