LCD Electronic Thermostat
EXT-CF24-D202-AF, EXT-CF24-D402-AF
Installation Manual
Mounting Method
1
open the clip with screw driver
2
unplug the connector
3
wiring
4
mount it with screws
5
plug in the connector
6
close it with clip
