Belimo LF-2 Series - Mounting Accessories LF

ZG-LF3
Damper linkage kit
for side mounting
(with 2 ball joints KG8)
ENG-93001-93227-01.00 • ZSD • Subject to technical changes
11
Mounting accessories LF...
K6-1
Spindle clamp
Suitable for damper spindles 16...20 mm
diameter.
The spindle clamp is secured to the ac-
tuator by means of a circlip.
K6-1
16...20
KH-LF
Crank arm with slot width 8.2 mm
Suitable for damper spindles 8...16 mm
diameter.
The crank arm is secured to the actuator
by means of a circlip.
KH-LF (Application example see page 14)
8...16
KH-LF1
Crank arm with slot width 8.2 mm
Suitable for damper spindles 16...20 mm
diameter.
The crank arm is secured to the actuator
by means of a circlip.
16...20
ZG-LF3 (Application example see page 14, fig. 2)
ZDB-LF
Angle of rotation limiting and pointer
The pointer is secured to the actuator by
means of a circlip.
ZDB-LF (Application example see page 13)
ZG-LF1
Damper linkage kit
for flat mounting
(with 2 ball joints KG8)
ZG-LF1 (Application example see page 14, fig. 1)
ZG-LF2
Damper linkage kit
for flat mounting
(without ball joints KG8)
m0039712
m0040712
m0041712
m0042712
m0043712
