Belimo LF-2 Series - General Mounting Accessories

m0063803
AV10-18
240
KG8
KG10
KH8
ENG-93001-93227-01.00 • ZSD • Subject to technical changes
12
General mounting accessories
KH8
Universal crank arm
Zinc-plated steel; suitable for damper
spindles
Ø 10...18 mm or
10...14 mm, slot width 8.2 mm.
KG8
Ball joint
Zinc-plated steel; suitable for use with KH8
universal crank arms and round steel rod
Ø 8 mm.
KG10
Ball joint
Zinc-plated steel; suitable for use with KH8
universal crank arm and round steel rod
Ø 10 mm.
AV10-18
Universal spindle extension
Suitable for damper spindles 10...18 mm
diameter.
If an AV10-18 is to be used in conjunction
with an LF..., the actuator must be fitted
with a K6-1 spindle clamp.
