sent over the port, the LED blinks rapidly. ORANGE indicates a 10Base-T
connection.
OFF No device is connected
Orange
Ethernet link is up and
10Base-T device connected
Orange—blinking
When 10Base-T device
transmitting or receiving data
Green
Ethernet link is up and
100Base-T connected
Insert
LAN
Icon
Green—blinking
When 100Base-T device
transmitting or receiving data
3. WLAN Status LED
The WLAN Status LED is solid GREEN when you enable the wireless LAN
function. It flashes when the Router is transmitting or receiving data wirelessly.
OFF WLAN is off
Green WLAN is up and connected
Insert
WLAN
Icon
Green—blinking
When transmitting or receiving
data
4. ADSL LED
The ADSL LED flashes GREEN during negotiation with your ISP. It stays
GREEN when the Router is connected properly to your ADSL service.
OFF No ADSL connection
Green – blinking Negotiating connection
Insert
ADSL
Icon
Green ADSL link is up and connected
5. Internet LED
The Internet LED shows you when the Router is connected to the Internet. When
the LED is OFF, the Router is NOT connected to the Internet. When the LED is
solid GREEN, the Router is connected to the Internet. When the LED is blinking,
the Router is transmitting or receiving data from the Internet.
OFF No Internet connection
Green Connected to the Internet
Green – blinking
When transmitting or receiving
data
Insert
Internet
Icon
Red Failed to get IP
Back Panel
[Insert: 9630-4 back image w/ arrows to ports]
6) [Insert: icon] DSL Line
