H. PLACE the Flat Panel mounting system against the REAR of the Furniture Cabinet with the L-shaped base of
the Flat Panel Mounting System frame underneath the cabinet and facing forward as shown in Fig. 5. ALIGN
the cutout slots in the frame with the threaded inserts in the rear of the Furniture Cabinet. SECURE the Flat
Panel Mounting System to the cabinet using the LONG 60mm bolts (5), or the proper ones that were included
with the Fur
nitur
e Cabinet. TIGHTEN FULLY BUT DO NOT OVERTIGHTEN.
5
Wood Cabinet
Fig. 5
