Bella 580 C - Wiring Diagrams

33
26. Wiring diagram
530 HT
ENG
CIRCUIT BREAKER
CONN.
SWITCH CABLE
N:O/COLOR
SIZE
mm2
FUNCTION
N:O AMP
1,5
F1
10
BLACK
WHITE/GREEN
WHITE
1,5
1,5
1,5
WIPER SB
TO MINUS INPUT
WIPER SB
WIPER SB
RED 1,5F2
10
NAV. LIGHTS
1,5
F3
10
1,5F4
10
EXTRA
1,5
F5
10
12 V DC OUTLET
6
RED + INPUT
RED
RED
BLACK
BLACK
6
35
35
6
F6
25
BATTERY SWITCH
+ INPUT TO SWITCH PANEL
TO ENGINE
TO ENGINE
- INPUT TO SWITCH PANEL
BLACK
Navigation lights
Windshieldwiper
(F1) Windshieldwiper
(F2) Navigation lights
(F3) Empty
(F4) Cabin lights
(F5) Power outlet
Switches
Fuses
Empty
Wiper
Nav. lights
F1
F2
F3
F4
F5
