Bella 580 C - Page 159

26. Wiring diagram
35
580 C
ENG
1,5
F1
10
PINK
WHITE/BLUE
WHITE/GREEN
1,5
1,5 WIPER 1
WIPER 2
WIPER CONT.
GREEN/BLACK
BLUE
1,5
F4
10
OUTLET 12V DC
1,5
F3
10
ANCOR LIGHT
6
RED + INPUT
RED
RED
BLACK
BLACK
6
35
35
6
F1
25
BATTERY SWITCH
+ INPUT TO SWITCH PANEL
TO ENGINE
TO ENGINE
- INPUT TO SWITCH PANEL
RED 1,5
F2
10
NAV. LIGHTS
XXX EXTRA *(INSTRUM LIGHT )1,5
YELLOW 1,5
CABIN LIGHTS
BLUE 1,5
ECHO *
CIRCUIT BREAKER
CONN.
SWITCH CABLE
N:O/COLOR
SIZE
mm2
FUNCTION
N:O AMP
(F1) Windshieldwiper
(F2) Navigation lights
(F3) Anchor light
(F4) Cabin lights, power outlet and
indicator light
F4
F3
F2 F1
4 3 2 1
5
Anchor light (3)
Navigation lights (2)
Windshieldwiper (1)
Cabin lights (4)
Switches
Power outlet (5)
Fuses
