This document provides a comprehensive guide for the Bellababy Baby Walker, model BLA-228, designed for infants aged 7-15 months. The product is manufactured by Bellababy Medical Devices Inc. and is made from PP/Polyester.

Function Description

The Bellababy Baby Walker serves as a mobility aid for babies, allowing them to explore their surroundings while providing support. It can also be converted into a push walker for continued use as the child grows. The walker features a musical play tray to engage the child and a padded seat for comfort.

Important Technical Specifications

Model: BLA-228
Target Age: 7-15 months
Batch Number: 230301
Product Material: PP / Polyester
Weight Capacity: The walker is designed to support children weighing approximately 7 months and over, and is not intended for children weighing more than 33 lbs/15 kg.
Height Settings: The leg is equipped with 3 height settings, adjustable to best suit the child's height.
Power Source for Music Tray: Requires two 1.5V AA batteries.

Usage Features

Safety Warnings and Precautions:

General Safety: Read all instructions carefully before assembly and use. Keep the manual for future reference. The child may suffer injury or worse if these instructions are not followed. Before assembly and use, remove and dispose of all plastic bags, packaging, and other packing items. Keep them out of reach of children.
Pre-use Check: Before assembly, check and confirm all components are not damaged during transportation. After assembly, regularly check the product for breakages or damage. If the product is broken or damaged in any way, keep it out of reach of children.
Assembly: The product must only be assembled by an adult. For the correct assembly procedure, please refer to the following instructions.
Stairway Hazard: To avoid serious injury or death, ensure all stairways and flights of steps are securely blocked before using the walker.
Supervision: Do not use the baby walking frame if any components are broken or missing. It should be used only for short periods of time (e.g., 20 minutes or so). It is intended to be used only by children who can sit unaided (i.e., aged approximately 7 months and over), and is not intended for children weighing more than 33 lbs/15 kg.
Replacement Parts: Do not use replacement parts other than those approved by the manufacturer or distributor.
Movement and Stopping: Clean all moving and braking components regularly to ensure effective long-term stopping performance.
Surface Use: Use only on flat surfaces free of objects which could cause the walker to tip over.
Child Supervision: Never leave the child unattended and always keep them in view while in the walker.
Movement Range: Note that the child will be able to reach further and move more rapidly when in the walking frame.
Collision Prevention: Prevent access to stairs, steps, uneven surfaces, slopes, or unstable floors, as well as swimming pools and other sources of water. Prevent collisions with glass (e.g., in doors, windows, and furniture etc.).
Burn Prevention: To avoid burns, keep the child away from hot liquids, cooking appliances, radiators, space heaters, fireplaces, etc.

Assembly Instructions:

1. Top Tray Assembly:

Parts Required: Top tray, padded seat, 6 legs (x 2), 10 screws (x 8), screwdriver.
Steps:
1. Prepare the padded seat by unscrewing the red cap found on the back (do not discard).
2. Insert the seat into the slot in the top tray.
3. Insert the two nuts on the pad into the two corresponding holes in the top tray.
4. On the back, reattach and tighten the red screw cap.
5. Fasten the screws on both sides of the pad into their respective holes.
6. Insert the outermost button into the large hole then drag it backwards into the smaller hole to lock it in place.
7. Unscrew the long bolt under the top tray.
8. Insert the strap at the front of the pad into the screw slot, then push the bolt through the hole in the strap. (Note: there are 5 holes in the padded straps, so this can be adjusted based on the child's needs).
9. Screw the bolt back in and tighten to hold the strap in place at the preferred length.
10. Keeping the back of the top tray facing up, align the legs with the semi-circular slots on either side of the top tray, and insert.
11. Place screws in each of the four holes on the inner side of each leg and affix using a screwdriver.
12. Ensure all attached components are firmly secured.

2. Base Assembly:

Parts Required: Musical play tray, walker base, flywheel, step brakes (x 2), universal wheels (x 4), bumper, screws (x 8), screwdriver.
Steps:
1. Prepare the base, 6 screws, and two flywheels, and turn the base upside-down.
2. Insert the flywheels into the end hole on the base (keeping the hole of the black insert part facing upwards). Note the unsecured end panel.
3. Lift the end panel up.
4. Place screws in the holes on both sides of the black shaft and tighten with a screwdriver.
5. Lower the end cover, place one screw and tighten it with a screwdriver, and secure the end cover. Repeat this process (from (b)) to attach the flywheel on the other side.
6. Insert the four universal wheels into the holes on the base as indicated.
7. Placement of the wheels.
8. Insert the 2 step brakes into the rectangular slots at the front of the base as indicated.
9. Placement of the step brakes.
10. After the installation is complete, as shown in the figure.
11. Turn the base over and insert the bumper strip into the two holes at the end of the base.
12. Place the fully assembled top tray into the slots on the base, and press the button on the inside of each leg so they can be depressed as far as required. Note the leg is equipped with 3 height settings, so the height can be adjusted to best suit the child.
13. The button (set at the highest level) and the 3 height settings on the inner side of the base.
14. Remove the cover from the battery compartment at the bottom of the music tray, insert two 1.5V AA batteries, with positive and negative terminals properly aligned, and reattach the cover with the screw.
15. The music panel can be conveniently placed on the dinner tray and removed when necessary.

3. Converting the Baby Walker into a Push Walker:

Steps:
1. Remove the bumper strip.
2. Push the buttons on each sides of the top tray to adjust its angle.
3. There are three angles to choose from, and once adjusted to the required setting the walker mode is ready for use.

Maintenance Features

To ensure the longevity and safety of the walker, regular maintenance is crucial:

Cleaning: When cleaning the cloth cover, avoid scrubbing it in water. Instead, use a household implement such as a brush or sponge to gently wipe away any stains.
Storage: Avoid using or storing the walker in a damp (wet), cold, or hot environment for extended periods of time.
Safety Check: When not in use, pay attention to maintenance and care, and keep it in a safe place.
Component Check: Check regularly for loose or damaged parts or broken wires, and replace damaged parts if necessary.

For any inquiries regarding product information, assembly, or missing accessories, please contact Bellababy Medical Devices Inc. via service-us2@bellababy-med.com or service-eu@bellababy-med.com.
