1. Top tray Assembly Instruction
Parts required:
1. Top tray; 2. Padded seat; 6. Legs (x 2); 10.
Screws (x 8); and 11. Screwdriver
Steps:
1. Prepare the padded seat by
unscrewing the red cap found on
the back (do not discard).
2. Insert the seat into the slot in
the top tray.
3. Insert the two nuts on the pad
into the two corresponding
holes in the top tray.
4. On the back, reattach and
tighten the red screw cap.
5. Fasten the screws on both
sides of the pad into their
respective holes.
6. Insert the outermost button
into the large hole then drag it
backwards into the smaller hole
to lock it in place.
