Belling BGH604WBG - Installation Cutout Drawings

17
Installation
60cm Stainless Steel Cooktop
BGH604WSS
501
45
475
555
35
582
Gas Inlet Point
470
550
60
45
500
45
480
560
50
579
Gas Inlet Point
470
550
48
35
Installation Cutout Drawings
60cm Glass Cooktop
BGH604WBG
Install Range Hoods and Exhaust Fans in accordance with the
manufacturer's instructions, no closer than 600mm above the
highest part of the cooking surface for Range Hoods and 750mm
for Exhaust Fans.
