3.3. WIRING AND SAFETY OF BUILT_IN OVEN
The instructions given below must be followed without fail during wiring :
The earthing cable must be connected via the screw with the earthing mark. Supply cable
connection must be as shown in Figure 1. If there is no earthed outlet conforming to
regulations in the installation environment, call the Authorized Service immediately.
The earthed outlet must be in close vicinity of the appliance. Never use an extension cord.
The supply cable should not contact the product’s hot surface.
In case of any damage to the supply cable, make sure to call the Authorized Service. The
cable must be replaced by the Authorized Service.
Wiring of the appliance must be performed by the Authorized Service. H05VV-F type
supply cable must be used.
Faulty wiring may damage the appliance. Such a damage will not be covered under the
warranty.
8
Wiring of the appliance must be performed by the Authorized Service. The appliance is
designed to connect to 220-240V~ electricity. If the mains electricity is different than the value
given, call the Authorized Service immediately. The appliance is designed for using with plug
ofor fixed connection to the mains. It is necessary that you install a double pole switch
between the product and the electricity supply (mains), with a minimum gap of 3 mm between
the switch contacts. (20A rated, delay function type).
The appliance is designed to connect to 220-240V~ electricty is different than the value
given above, call the Authorized Service immediately.
The Manufacturer Firm declares that its bears no responsibility whatsover for any
kind of damage and loss arising from not complying with safety norms!
Figure 1
BLUE
BROWN YELLOW+GREEN
