Belshaw Brothers H&I-2 - Page 12

DIAGRAMS PAGE
4
© Belshaw Adamatic Bakery Group, Auburn, WA 98001 USA. All Rights Reserved. 07/17
DIAGRAM: H&I-2/4 CONSOLIDATED BILL OF MATERIAL
USE FOR
H&I-2, H&I-4 (All Models)
Item Numbers: 84900112, 849001221,
84900114, 84900124
TO IDENTIFY MODEL AND ITEM NUMBER, SEE DATA TAG ON ICER
Page 1 of 1
MODEL H&I - 2 H&I - 2 H&I - 4 H&I - 4
84900112 849001221 84900114 84900124
120V 240V 120V 240V
2 Bowls 2 Bowls 4 Bowls 4 Bowls
Component Part Component Name Quantity Quantity Quantity Quantity
AMD-0012
THERMOMETER 0-220 LO TEMP
TAYLOR
1 1 1 1
C800G-0201-1
MANUAL GAS VALVE 1 IN 175PSI
MILWAUKEE #BB-2-100
1 1 1 1
H&I-1700
PHTM - ELECTRICAL ASSEMBLY-120V 1 1
H&I-1701 PHTM-ELECTRICAL ASSEMBLY; 240V 1 1
H&I-2-0004 R03 COVER,2 HOLE 1 1
H&I-4-0007 R08 COVER,4 STATION 1 1
H&I-2-0007 LABEL; THERMOSTAT 1 1 1 1
H&I-2-0500 R06 FRAME ASSEMBLY 1 1
H&I-4-0502 R10 FRAME WELDMENT 1 1
H&I-2-1000 PHTM-TUB ASSEMBLY 1 1
H&I-4-1002 TUB ASSEMBLY 1 1
H&I-4-0506 PHTM-LABEL KIT 1 1 1 1
H&I-4-1005 WIRE HARNESS 1 1 1 1
H&I-4001 TAB WD H&I-2, 4, 6, ICING TABL 1 1 1 1
966-0010.A 8 QT MIXING BOWL SS 2 2 4 4
966-0011
12" ALUM LID FOR 8QT BOWL ALEGACY 2 2 4 4
HG18-0031-4
CASTER NSF 4" 7/16 DIA W/O BRAKE 2 2 2 2
HG18-0031B-4 CASTER NSF 4" DIA W/BRAKE 2 2 2 2
905-0054-1.25 PLASTIC END CAP 1-1/4 SQ BLK 4 4 4 4
ITEM NUMBER
BILL OF MATERIAL
NUMBER OF BOWLS
VOLTAGE
