Spare Parts Lists
Structure Parts List
Note: 1. When replacing any of components, be sure to use only manufactures specified parts shown in the parts list.
2. Important safety notice: Components identified by “ ! “ mark have special characteristics important for safety.
Ref.
No.
PART NUMBER
Part Name & Description Pcs Remarks
1 JKM3350-1 Top Cover 1
2 JMZ0001A Thermoplastic tube 2
3 JMZ0001B Thermoplastic tube 1
4 JSB0002 POWER Switch 1
5 JWV0005 Power wire ( 2P) 1
6 JGR4360 Rear side panel 1
7 JMK4350-2 Chassis 1
8 JKA2302 Foot 2
9 JMN0002 Clip 3
10 JMN2301 Stanchion 7
11
JMN2302 Stanchion 2
12 JGM2301 Power board Rubber 2
13 JWV12P2.5A Connecting wire (12pin) 1
14 JWJ30P1.0T80 Flexible flat cable(30P) 1
15 JYP3350P-2 Front Panel 1
16 JGK4350-BSA Logo nameplate 1
17 JMN3350 Bracket 1
18 JWV7P2.5A Connecting wire (7pin) 1
19 JWV6P2.5B Connecting wire (6pin) 1
20 JMG3350 Foot rubber mat 2
21 JQL0011D adhesive tape (double side) 1
22 DV34
Optical pickup unit 1
23 KZG-D01
Holder of mechanism 1
24 JWJ24P0.5T190
Flexible flat cable(24P)
1
25 JWV6P2.0Y160
Connecting wire (6 pin, pitch=2.0mm, L=160mm) 1
26 JWV5P2.0T140
Connecting wire (5 pin, pitch=2.0mm, L=140mm) 1
27 JMG1313
Board Rubber 2
28 JMR0002
Mechanism mat 2
29 BA2.6×8
Screw 2
30 FM3×6 Screw 4
31 PA3×8 Screw 10
32 PWB3×8 Screw 2
33 PWB3×8-B Screw 8
34 PWM3×6 Screw 9
35 PWM3×8 Screw 4
36 PWM3×11 Screw 2
37 PWM3×15 Screw 7
