Electric Parts List
Note:
1. When replacing any of components, be sure to use only manufactures specified parts shown in the parts list.
2. Important safety notice: Components identified by “!” mark have special characteristics important for safety.
3. This product uses a laser diode. Refer to caution statements.
4. Capacity valuse are in microfarads (µF) unless specified otherwise, P=Pico-farads (pF), F=Farads (F); Resistance
vallues are in ohms, unless specified otherwise, 1K=1,000(OHM),1M=1,000K(OHM).
POS. NO PART NUMBER DESCRIPTION Pcs Remarks
JEP4364A Output Board Module 1
JEP3353A Operate Board Module
1
JEP4360P Power Board Module 1
JEP4361A
Decode Board Module 1
JEP4364A Output Board Module 1
JJB4364A-1 PCB 1
C701 ECA1CHG221 Aluminum electrolytic capacitor 220uF 1
C702,C709,C714,C713,C720 HLT1HC220K05F3D Capacitor,ceramic 22pF 5
C703,C706,C708 HLT1HS101K05F3D Capacitor,ceramic 100pF 3
C715 HLS1HF104Z07F3D Capacitor,ceramic 100nF 1
C711,C712,C704,C705,C716,
C717,C718,C719
HLK1HB102K05F3D Capacitor,ceramic 1000pF 8
FB702,FB703,FB704,FB705,
FB706,FB707,FB709,FB713
,FB714,FB721,W703,W704,
W705,FB717,FB718,FB719,
FB720
EN9589 Ferrite bead 17
JS701 JJS30P1.0S Connector 30P 1.0mm 1
X701,X702 VJR0978 Earthing strip 2
J701 ASW-03 Terminal (CVBS+S-VIDEO) 1
J702 CS-106 Terminal (SCART) 1
J703 AV6-8.4-13/PB Terminal (5.1 channel Audio) 1
J704 AV4-8403A Terminal (Coaxial + YPbPr) 1
J705 TPK-TX178A Terminal (Optical) 1
W701,W702,W706,W707,
W708,W709,W710
Z-W6NL-H10 Jumper 10mm 7
R701 ERD25TJ3R9B Resistor 1/4W 3.9Ω ±5% 1
JEP3353A Operate Board Module
1
JJB3353A PCB
1
E501,E502 ECEA1AKA101-H5 Aluminum electrolytic capacitor 100uF 2
C502 HLS1HF104Z07F3D Capacitor,ceramic 100nF 1
JP502 JJU6P2.5A Connector 6P 2.5mm 1
JP501 JJU7P2.5A Connector 7P 2.5mm 1
D502,D503,D504 1N4148 Diode 3
U502 AT136BT-12DW 36KHz IR Receiver 1
R501 ERD25TJ100D Resistor 10Ω ±5% 1
