Belson BSA-3750 - Page 39

DVD - DivX Player - BSA3750
39
R502 ERD25TJ473D Resistor 47K ±5% 1
R504,R505,R506,R507,R508,
R509,R510 ERD25TJ103D Resistor 10K ±5% 7
SW501,SW502,SW503,
SW504,SW505,SW506 EVQPAE05R Light Touch Button 6
U501 HNV05SS32 VFD 1
JMG2302 VFD rubber mat 2
W502,W503,W505,W506 Z-W6NL-H5 Jumper 5mm 4
W501,W504 Z-W6NL-H7.5 Jumper 7.5mm 2
U503 D16312 IC 1
JEP4360P Power Board Module 1
JJB3302A PCB 1
C609 C610
ECA1HHG100 Aluminum electrolytic capacitor 10uF
2
C627
ECA1CHG102 Aluminum electrolytic capacitor 1000uF
1
C614
ECA1CHG222 Aluminum electrolytic capacitor 2200uF
1
C616 C618 C620 C625 C617
ECA1EHG221 Aluminum electrolytic capacitor 220uF
5
C622
ECA1EHG471 Aluminum electrolytic capacitor 470uF
1
C621
ECA1HHG101 Aluminum electrolytic capacitor 100uF
1
C603
HPW680M2GN30 Aluminum electrolytic capacitor 68uF
1
C601 C602
AC275V-104K Capacitor, 275V104
2
C605
HLK1HB471K05F3D Capacitor,ceramic 470pF
1
C606
HLS1HF104Z07F3D Capacitor,ceramic 100nF
1
C631 C611
HCM08051HY5V224ZB3 Capacitor,ceramic 220nF
2
C608
ECKA3A472MBP Capacitor,ceramic 4.7nF
1
CY603
HJE222M12H3 Capacitor,ceramic 2.2nF
1
CON602
JJS0002
AC Connector 2P pitch=7.92mm
1
CON601
K2AA2B000004 AC inlet
1
D601 D602 D603 D604 1N4007-H02-1 Diode 4
D605 D607 D617 FR104-H02-1 Diode 3
D606 BZX55C16V Zener diode 1
D608 D613 D615 D616 FR107-H02-1 Diode 4
D610 1N5822-M26 Diode 1
D618 D620 RL205-H14 Diode 2
D619 BZX55C9V1 Zener diode 1
F601 JLF0001 Choke 1
J603 Z-W6NL-H7.5 Jumper 7.5mm 1
J601 J602 J605 J607 J608,
CY604 Z-W6NL-H10 Jumper 10mm 6
JS601
JJU12P2.5A Connector 12P 2.5mm
1
JS602
JJU6P2.5A Connector 6P 2.5mm
1
L602
ELC10D100E Inductor 10uH
1
L603 L605
ELEAA5R6JA Inductor 5.6uH
2
R601
ERD25TJ753B Resistor 75K ±5%
1
R604 R605
ERD25TF1R0B Resistor 1Ω±5%
2
