Bematech LE1015 User Manual

10
4 Setup and Driver Installation
4.1 Control Buttons
There are 5 keys for user to set up the monitor. The following describes
functions of these Keys.
P
Power
Turn the LCD power on and off. When the power is on, the LED is
green, When in standby, LED is orange.
M
Menu / Function Select Down
Press this button to invoke the OSD menu. When OSD menu is
displayed, press this button to select the highlighted menu or
function.
+
Adjust [ + ]
Increase volume. When in OSD menu, select next function. When
an OSD item is selected, this button increase the option value.
-
Adjust [ - ]
Decrease volume. When in OSD menu, select previous function.
When an OSD item is selected, this button decrease the option value.
A
Auto Adjust
Press this button to apply the monitor setting automatically. When
OSD menu is displayed, this button exit the selected function.
A
-
+
M
P

Bematech LE1015 Specifications

General

Aspect ratio	4:3
Screen shape	Flat
Response time	12 ms
Display diagonal	15 \
Touch technology	Multi-touch
Display brightness	250 cd/m²
Display resolution	1024 x 768 pixels
Display technology	LCD
Touchscreen technology	Resistive
Viewing angle, vertical	145 °
Contrast ratio (typical)	800:1
Display diagonal (metric)	38.1 cm
Viewing angle, horizontal	160 °
Product color	Black
Audio input	1
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	30 W
Power consumption (off)	0.5 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Wall mountable	No
Panel mounting interface	100 x 100 mm

Weight and Dimensions

Depth (without stand)	230 mm
Width (without stand)	364 mm
Height (without stand)	326 mm
Weight (without stand)	5500 g
