INSTALLATION GUIDE
BEFORE INSTALLATION
Do not plug the power cord in until installation is complete.
Please contact our service center at 847.458.2334 for alternate
fittings or assistance with this process.
1. Turn Off Water
Turn off the water shut-off
valve. Drain the toilet tank
completely by flushing the
toilet. Unscrew the hose
connected to the toilet tank.
Existing
Toilet Hose
2. Remove Toilet Seat
Unscrew the nuts on both sides of
the toilet to release the existing
toilet seat from the toilet.
3. Install Catch Plate
Insert the top mount anchors into the toilet bolt holes. Insert the mounting bolts
through the guides, catch plate, and mounting holes and into the top mount rubber
anchors. Fasten with a phillips screwdriver to secure the catch plate on the toilet.
INSTALLATION
Align the bidet seat with the catch
plate and slide it all the way back
until you hear a click.
4. Install Your HD-7500
Bolt
Bolt Guides
Catch Plate
Top Mount
Anchors
Back of
toilet
To Next Page
