FUNCTIONS
1 Handle
2 Welding voltage meter
3 Welding current meter
4 Regulator - wire feeding speed (MIG mode), welding current (MMA mode)
5 Regulator - welding voltage (MIG mode)
6 Positive output connector
7 Polarity switching cable
8 MIG/MMA mode selector
9 2T/4T mode selector
10 Gas test
11 Inductor adjustment (MIG mode), arc force (MMA mode)
12 Negative output connector
13 MIG welding torch connector
14 Gas supply inlet
15 Power switch
16 Power input cable and plug
17 Fan
18 Quick wire feeding button
19 Wire feeder
20 Wire spool mount spindle
21 Spool gun/MIG gun switch
22 Wire feed control socket
GAS & NOGAS Application connection:
Gas application (using solid cored welding wire: polarity switching cable connects
“+”, earth clamp connects “-”, torch connect to “
” and fasten it.
No gas application (using flux cored welding wire: polarity switching cable connects
“-”, earth clamp connects “+”, torch connect to “
” and fasten it.
Note: Inductor adjustment is to set the welding arc force, 0 is standard setting
value.
If the code “E01” is shown on the display, it means the machine is over heated
and under protection, please wait till the display “E01” is o.
