1150-003
INVERTER MULTI-PROCESS WELDER KIT
22
26. To check the wire’s drive tension,
press and hold Trigger to feed the
wire against a piece of wood from
2 to 3 inches away. If the wire
stops instead of bending, unplug
the Welder, slightly tighten the
Feed Tensioner clockwise, and try
again. If the wire bends from the
feed pressure, then the tension is
set properly. Before proceeding,
turn OFF the Power Switch and
unplug the Power Cord from its
electrical outlet.
27. Turn OFF the Power Switch and unplug
the Power Cord from its electrical outlet.
28. Close the Door. Make sure Door is securely latched.
29. Select a Contact Tip that is compatible with the welding
wire used. Slide the Contact Tip over the wire and thread
it clockwise into the MIG Gun. Tighten the Contact Tip.
30. Replace the Nozzle and cut the wire o at 1/2"
from tip (1/2" stickout).
OPERATION
