15
WARNING
When servicing, use only original equipment replacement parts. The use of any
other parts may create a safety hazard or cause damage to the wet/dry vacuum
Any attempt to repair or replace electrical parts on this wet / dry vacuum may
create a safety hazard unless repairs are performed by a qualified technician.
PARTS LIST
Key # Part # Part Name Quantity
1
1277-027-001 Handbar screw 4 x 16 2
2
1277-027-002 Handbar 1
3
1277-027-003
Cord Sleeve 1
4
1277-027-004 Label 1
5
1277-027-005 Top cover 1
6
1277-027-006 Motor cover 1
7
1277-027-007 Top cover screw 4 x 16 2
8
1277-027-008 Power cord strain relief 1
9
1277-027-009 Power cord 1
10
1277-027-010 Bottom cover 1
11
1277-027-011 Top sealing ring of motor 1
12
1277-027-012 Motor 1
13
1277-027-013 Bottom sealing ring of motor 1
14
1277-027-014 Motor noise reduction sponge 1
15
1277-027-015 Bottom frame for motor 1
16
1277-027-016 Safety valve float 1
17
1277-027-017 Bottom cover basket 1
18
1277-027-018 Bottom cover basket screw 5 x 20 10
19
1277-027-019 Handle bar screws m5 x 60 2
20
1277-027-020 Handle bar mounting spacers 2
21
1277-027-021 Push rod 1
22
1277-027-022 Tank 1
23
1277-027-023 Bottom base 1
24
1277-027-024 Rear wheels cover 2
25
1277-027-025 Rear wheels 2
26
1277-027-026 Rear wheels axle screw 5 x 35 2
27
1277-027-027 Rear wheels axle 1
28
1277-027-028 Swiveling casters 2
29
1277-027-029 Water outlet hose hanger 1
30
1277-027-030 Hanger fastening screws 4 x 12 4
