Benchmark 1347-001 - Page 25

1347-001
20V MAX 7-1/4” SLIDING COMPOUND MITRE SAW
24
Part # Part Name Quantity
1347-001-31 FRONT COVER 1
1347-001-32 6001 BEARING 1
1347-001-33 M4X10 SCREW 2
1347-001-34 FASTENING BLOCK 1
1347-001-35 GEAR 1
1347-001-36
12 SHAFT SNAP RING
1
1347-001-37
COPPER POWDER BUSHING (
12* 8*10)
1
1347-001-38 UPPER GUARD 1
1347-001-39 M5X12 SCREW 1
1347-001-40A HEIGHT ADJUSTED BUTTON (M6X50) 1
1347-001-40B HEIGHT ADJUSTED BUTTON 2
1347-001-41 KNURL NUT M6 1
1347-001-43
O TYPE RING
25.7*1.8
1
1347-001-44 6000 BEARING 1
1347-001-45 AIR GUIDE 1
1347-001-46 ROTOR ASSEMBLY 1
1347-001-47 607 BEARING 1
1347-001-48 RUBBER SLEEVE (MATCH 607 BEARING) 1
1347-001-49 ST4.2X70 SCREW 2
1347-001-50 STATOR ASSEMBLY 1
1347-001-51 RATING LABEL 1
1347-001-52 HOUSING 1
1347-001-53 WARNING STICKER 1
1347-001-54 SPIRAL SPRING 2
1347-001-55 BRUSH HOLDER 2
1347-001-56 BRUSH ASSEMBLY 2
1347-001-57 ST4X10 SCREW 4
1347-001-58 MOTOR COVER 1
1347-001-59 WARNING STICKER 1
1347-001-60 BLADE 1
1347-001-61 OUT FLANGE 1
1347-001-62 M8X16 SCREW (REVERSED THREAD) 1
1347-001-63 M6 LOCKING NUT 2
1347-001-64 GUARD SUPPORT 1
1347-001-65 M5X10 SCREW 1
1347-001-66 M5X10 SHAFT SCREW 1
