PARTS LIST
WARNING: When servicing, use only original equipment replacement parts.
The use of any other parts may create a safety hazard or cause damage to the saw.
Any attempt to repair or replace electrical parts on this saw may create a safety hazard
unless repairs are performed by a qualified technician.
For more information, call the Toll-free Helpline, at 1-866-349-8665, Monday – Friday
from 9 am to 5 pm Eastern Standard Time.
Always order by PART NUMBER, not by key number.
Part # Part Name Quantity
1347-001-1 TAP SCREW M5X35 6
1347-001-2
WASHER INNER HOLE
5
13
1347-001-3 SCREW ST4.2X13 8
1347-001-4 UPPER GRIP WITH OVERMOULD 1
1347-001-5 TRIGGER BUTTON ASSEMBLY 1
1347-001-6A BATTER FOOT (JD LOWER) 1
1347-001-6B BATTER FOOT (JD UPPER) 1
1347-001-7 TERMINAL BLOCK 1
1347-001-8 LOWER GRIP WITH OVERMOULD 1
1347-001-9 WORK LIGHT COVER 1
1347-001-10 SMALL SWITCH 1
1347-001-11 SCREW M5X14 5
1347-001-12 SCREW ST4.2*16 2
1347-001-13 TRIGGER SPRING (Ø1XØ7X35) 1
1347-001-14 MICRO SWITCH MSF-2130, 30A/42VDC 1
1347-001-15 LED PCB (DK-D282-4, INPUT 18V, OUTPUT 0.5W) 1
1347-001-16 DUST BAG 1
1347-001-17 SHAFT SCREW M6X12.5 1
1347-001-18 SCREW M4X10 19
1347-001-20 Ø4 SPRING WASHER 10
1347-001-23 S45C (3G185 2MMLONGER)RETENTION PIN 1
1347-001-24
6 SNAP SPRING
1
1347-001-25 LOCKING PIN SPRING 1
1347-001-26 LOGO LABEL 1
1347-001-27 INNER PLATE 1
1347-001-28 FLAT KEY 3X3X20 1
1347-001-29 OUTPUT SHAFT 1
1347-001-30
SPRING WASHER (INNER HOLE
5)
8
