11
CUTTING HEIGHT ADJUSTMENT (Fig. 8)
ALIGN CUTTING PATH INDICATION ARROWS WITH PREVIOUSLY CUT
PATH
(Fig. 9)
• The cutting height of the mower adjusts from 1.375" - 3.15" (35mm - 80mm)
with 9 positions for adjustment height by moving the height adjustment levers to
the desired position.
• To achieve the lowest cutting position, one at a time, move the adjustment levers
on both sides, located next to the smaller wheels, up to the highest position.
• To achieve the highest cutting position, move the adjustment levers on both
sides to their lowest position.
• Other cutting heights are achieved by moving the adjustment levers to any stop
between the highest and lowest positions.
NOTE: The two adjustment levers MUST be set to the same position (height).
NOTE: Do not use wheels as a reference point for grass cut line.
Fig. 8
Fig. 9
Height adjustment
lever
