Benchmark 5125-025 - Chassis Assembly

25
Key # Part # Part Name Quantity
3100810201039001 Battery pack under bracket 1
3118920101049001 Inserting seat 2
3417820101027001 Internal wiring1 1
3422910101027001 Carbon brush line1 1
3422710101032001 Microswitch 1
392000101030001 Washer 1
3418830301027001 Internal wiring3 1
3419510501027001 Internal wiring5 1
36010112 Male terminal 2
36010101 6.3 inserting terminals 2
3422530101145001 Diode 2
3122550901069001 Wheel cover 4
3321500101138001 Cotter 4
33NHD0080101 Flange lock nut 4
3322580101020001 Bearing 8
3122580101031001 7" wheel 2
3322570101030001 Flat gasket 4
3360000201030001 Washer 1
3222575001020001 Front axle 1
3222580101057001 Front link 1
3252200201103001 Connecting rod buckle-2 2
3222570401060001 High tension spring 1
3390000401030001 Washer 1
3252200201053001 Axle pressing plate 8
3322530201030001 Washer 1
33SBAQA004160101 Screw 22
3252200401060001 Adjust lever knob spring 1
3252200501057001 Adjustment lever 1
33SJAQC005080101 Large flat head screw 1
3155000101094001 Heighten hand shank 1
3252200301020001 Adjusting rod rotation shaft 1
3152200101049001 Adjust lever block 1
3222575001057001 Back link 2
2.15
2.16
2.17
2.18
2.19
2.20
2.21
2.22
2.23
2.24
2.25
3.1
3.2
3.3
3.4
3.5
3.6
3.7
3.8
3.9
3.10
3.11
3.12
3.13
3.14
3.15
3.16
3.17
3.18
3.19
3.20
3.21
3.22
Chassis Assembly
