5125-025
40V MAX BRUSHLESS LAWN MOWER
24
PARTS LIST
WARNING: When servicing, use only original equipment replacement parts.
The use of any other parts may create a safety hazard or cause damage to the
brushless lawn mower.
Any attempt to repair or replace electrical parts on this lawn mower may create
a safety hazard unless repairs are performed by a qualified technician. For more
information, call the Toll-free Helpline, at 1-866-349-8665 Monday - Friday from
9am to 5pm Eastern Standard Time.
Always order by key number.
Key # Part # Part Name Quantity
1.1 33SBAQA006230101 Screw 4
3422580101004001 Brushless motor 1
33SBAQA004160101 Screw 3
3422580501092001 Controller 1
36040102 Double hole terminal sleeve 1
36010108 Female terminal 3
36040104 Single hole terminal sleeve 1
36010113 Female terminal 2
3122570101142001 Battey compartment base 1
3181000101053001 Pressing plate 1
33SBAQA004160101 Screw 28
3122580201030001 Washer 1
3222580101053001 Calibration panel 1
33SEADA004160101 Sunk screw 2
3122530101094001 Grip 1
3122540101069001 Cover 1
3122520101056001 Safety key 1
3222830101010001 Magnet 1
3222830201074001 Screw 2
3122540101053001 Plate 1
3122540201069001 Transparent cover 1
3100810101039001 Battery pack upper bracket 1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
2.9
2.10
2.11
2.12
2.13
2.14
Motor Assembly
Battery compartment Assembly
