5150-004
13 AMP ELECTRIC DETHATCHER
PARTS LIST
WARNING
When servicing, use only original equipment replacement parts.
The use of any other parts may create a safety hazard or cause damage to the 13 Amp Electric
Dethatcher. Any attempt to repair or replace parts on this 13 Amp Electric Dethatcher may
create a safety hazard unless repairs are performed by a qualified technician. For more
information, call the Toll-free Helpline, at 1-833-818-4111 – Monday-Friday from 9am - 5pm
Eastern Standard Time.
Always order by key number.
Number Part sku Part name Quantity
1 BVAO021001 Wheel cover 2
2 BVAO021002 Ø10*Ø20*1.5 gasket 4
3 BVAO021003 Pressplate 2
4 BVAO021004 Front wheel spindle assembly 1
5 BVAO021005 200 Wheel 2
6 BVAO021006 Front decorative panel 1
7 BVAO021007 Filter sponge NO. 2 1
8 BVAO021008 Filter sponge NO. 1 1
9 BVAO021009 Filter sponge NO. 3 1
10 BVAO021010 NUT 12*12*6 M8 2
11 BVAO021011 Pressplate 1
12 BVAO021012 Breakwind 1
13 BVAO021013 Housing cover 1
14 BVAO021014 Housing handle 1
15 BVAO021015 Grass bag fixing pin 1
16 BVAO021016 Spring 1
17 BVAO021017 Grass bag cover 1
18 BVAO021018 Torsion spring fixing pin 1
19 BVAO021019 Protector 17AMD 110Z+PTC 1
20 BVAO021020 Sandbag 1
21 BVAO021021 Base 1
22 BVAO021022 Back wheel spindle 2
23 BVAO021023
Screw ST5*25
2
24 BVAO021024 150 wheel 2
25 BVAO021025 Ø10*Ø20*1.5 gasket 2
26 BVAO021026 Wheel cover 2
27 BVAO021027 NUT M6*5 1
28 BVAO021028 NUT M5 1
29 BVAO021029
Bearing block
1
