Tilling Position
1. Ensure cupped washer is installed onto wheel axle.
2. The tiller wheels are directional. For best performance install the wheels with the
tire thread facing the direction as shown.
3. Slide the wheel hub onto the wheel axle.
4. Align the wheel hub hole with the hole in the axle and insert the locking pin.
5. Rotate the locking pin ring to lock the pin in position.
INSTALLING THE DEPTH REGULATOR
1. Insert the depth regulator from the bottom of the depth regulator bracket.
2. Insert the pin through the bracket and lever.
