MACHINE PARTS
When unpacking the machine, take care to gather all individual parts and fittings,
and do not damage the cutting deck when taking the machine off the pallet.
1. Machine
2. Steering connect shaft and Splined
hub
3. Towing kit
4. Bumper
5. Bumper bracket L
6. Bumper bracket R
7. Steering wheel cover
8. Steering wheel
9. Steering shaft cover
10. Operator’s manual
11. Nuts, bolts, washer, bushing
12. Seat
13. Tools and Starter key
14. Side deflector
15. Deck fixing plate
16. Mulching Kit
To prevent damage to the cutting deck, raise it to its maximum height and take
utmost care when taking the machine off the pallet.
