25-TON LOG SPLITTER - OWNER'S MANUAL
PARTS LIST
WARNING: When servicing, use only original equipment replacement parts.
The use of any other parts may create a safety hazard or cause damage to the
log splitter.
Any attempt to repair or replace electrical parts on this log splitter may create a
safety hazard unless repairs are performed by a qualified technician.
Customer Service / Tech Support 1-866-206-0888.
1 Clevis Pin Assy. 1
2 Cylinder 1
3 Elbow Fitting 1 2
4 Tube 1
5 Fitting 1
6 Valve Assembly 1
7 Elbow Fitting 2 1
8 Elbow Fitting 3 2
9 Nipple 1/2 NPT 1
10 Hex Nut M12x1.75 5
11 Lock Washer, M12 5
12 Wedge, 8in. 1
13 Hex Bolt, M12x75 1
14 Beam 1
15 Log Catcher 1
16 Support Arm Left 1
17 Support Arm, 1
Large Left
18 Hex Nut, M10 8
19 Lock Washer, M10 8
20 Flat Washer, M10 12
21 Support, Right 1
22 Lock Nut, M8 4
23 Flat Washer, M8 20
24 Rubber Damper 4
25 Hex Bolt, M10x30 8
26 Support Arm, 1
Large Right
27 Wheel, 4.8x8 in. 2
28 Pivot Bracket 1
29 Slotted Pin 1
30 Latch Rod 1
31 Spring 1
32 Flat Washer, 1/2 Inch 3
33 Beam Lock 1
34 Suction Filter 1
35 Straight Fitting 3/4 1
NPT to 1 Inch Tube
36 Straight Fitting 1
M3/4 NPT
37 Filter Base Assembly 1
38 Elbow Fitting 4 1
39 Suction Hose 1
40 High Pressure Hose 1
41 Oil Return Hose 1
42 Lock Washer, M8 12
43 Oil Filter 1
44 Hose Clamp 2
45 Hex Bolt, M8x45 4
46 Tank 1
47 Vent Cap 1
48 R-Clip 1
No. Description Qty. No. Description Qty.
