20
BW SERIES
5.2. USING THE SPRAY NOZZLES
WARNING!
High pressure in nozzle area. Risk of injury caused by improperly locked
nozzle.
When replacing nozzles with the engine running the trigger safety lock
MUST be engaged.
1. To connect or disconnect a spray tip pull back on the quick connect collar.
Insert or remove the spray tip then release the collar. Tug on the spray tip to
ensure it is secured. The tips are color coded and stored on the panel.
Nozzle Selection Guide
0° 15° 25° 40° 65°
Paint Stripping
Concrete
Deck
Gutters
Siding
Vehicles
Windows
Furniture
Detergent
