Benchmark MAIN User Manual

22
8.0 Flue Options
© Baxi Heating UK Ltd 2007
Key Accessory Size Baxi Code No
Concentric Flue System 100mm diameter
A1 Horizontal flue Terminal 5111073
A Horizontal flue Terminal (incl elbow) 5118489
B Flue extension 1000mm 5111074
C Flue Bend 93° 5111075
D Flue Bend (pair) 135° 5111085
U Pipe support 100mm 5111080
R Vertical flue adaptor 5111070
P Wall Liner 5111067
S Flue Terminal Deflector 5111068
Twin Flue System 80mm diameter
E Flue extension (pair) 1000mm 5111087
F Flue Bend (pair) 90° 5111072
G Flue Bend (pair) 135° 5111086
J Vertical flue boiler adaptor kit 5111079
H Vertical flue adaptor 5111084
W Pipe support (pair) 80mm 5111081
Vertical Flue Kits
K Vertical flue terminal 5111078
L Lead tile 25°/45° 246141
Lead tile 35°/55° 246142
M Roof cover plate 246143
N Flat roof flashing 246144
A
A1
B
K
R
D
C
N
U,W
S
L
H
J
M
E
G
F
P
8.3 Flue Accessories
