BENDIX EC-60 ABS-ATC ESP CONTROLLERS ADV User Manual

21
Active or Inactive Diagnostic Trouble Codes:
INDEX
How to interpret the first digit of messages received
when Active or Inactive Diagnostic Trouble Code Mode
1st
Blink
Code
Number
1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No faults (1,1)
2 . . . . . . . . . . . . . . . . .
Wheel Speed Sensors - page 22
3 . . . . . . . . . . . . . . . . .
Wheel Speed Sensors - page 22
4 . . . . . . . . . . . . . . . . .
Wheel Speed Sensors - page 22
5 . . . . . . . . . . . . . . . . .
Wheel Speed Sensors - page 22
6 . . . . . . . . . . . . . . . . . . . . . . . .
Power Supply - page 27
7 . . . . . . . . . . . . . .Pressure Modulator Valves - page 24
8 . . . . . . . . . . . . . .Pressure Modulator Valves - page 24
9 . . . . . . . . . . . . . .Pressure Modulator Valves - page 24
10
. . . . . . . . . . . . .Pressure Modulator Valves - page 24
11
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . J1939 - page 28
12
. . . . . . . . . . . . . . . . . . . Miscellaneous - pages 30-31
13
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ECU - page 29
14
. . . . . . . . . . . . . . . . Wheel Speed Sensors - page 22
15
. . . . . . . . . . . . . . . . Wheel Speed Sensors - page 22
16
. . . . . . . . . . . . .Pressure Modulator Valves - page 24
17
. . . . . . . . . . . . .Pressure Modulator Valves - page 24
18 . . . . . . . . Drive Axle Traction Control Valve - page 26
19 . . . . . . . Steer Axle Traction Control Valve - page 26
20 . . . . . . . . Trailer Pressure Modulator Valve - page 24
21 . . . . . . . . . . . . .Steering Angle Sensor - pages 33-33
22 . . . . . . . . . . . . . . . . .Yaw Rate Sensor - pages 34-35
23 . . . . . . . . . . . . Lateral Acceleration Sensor - page 36
24 . . . . . . . . . . Brake Demand/Load Sensors - page 37
Example: For a message sequence of:
3, 2 12, 4
For the first sequence go to page 22 and
for the second sequence go to page 30.
Go Here for Troubleshooting Tests
See Page 44 for Appendix A: J1587 SID and FMI Codes and Their Bendix Blink Code Equivalents

BENDIX EC-60 ABS-ATC ESP CONTROLLERS ADV Specifications

General

Category	Controller
Type	ABS-ATC ESP Controller
Model	EC-60
Manufacturer	Bendix
ABS	Yes
ATC	Yes
ESP	Yes
Voltage	12V/24V
Communication	J1939
Mounting	Chassis
Diagnostics	Supported
