40
ABS Component Connector Wire Wire Seal/ Terminal Terminal
Terminal Plug Lock Crimp Tool
Controller
Harness
12-Way AMP
MCP 2.8 (X4)
1718091-1
8-968974-1
8-968973-1
8-968972-1
927768-9
1 - 2.5 mm
2
X1-12 & 18
967634
N/A
Controller
Harness
17-Way AMP
MCP 2.8 (X1)
Controller
Harness
18-Way AMP
MCP 2.8 (X2)
Controller
Harness
15-Way AMP
MCP 2.8 (X3)
N/A
N/A
N/A
N/A
N/A
N/A
CHART 4 - EC-60
™
CONTROLLER COMPONENT CONNECTORS
539723-2
968873
1.0 - 2.5 mm
2
968874
2.5 - 4 mm
2
12040977
12015323
12034145
539635-1
ABS Modulator
Harness
3-pin Packard
Metri-Pack
280 Series
ATC Modulator
Harness
AMP Twist-Lock
(Bayonet)
ABS Modulator
Harness
AMP Twist-Lock
(Bayonet)
1-967325-2
1-967325-3
929975-1
12077411
929975-1
12155975
WS-24
™
Wheel Speed Sensor Connectors
Packard GT
150 series
Packard Metripack
150.2 series
Deutsch DTM06
series
Packard Metripack
280 series (female)
Packard Metripack
280 series (male)
Deutsch DT04
series
Standard round
two pin
N/A
N/A
N/A
N/A
Not Shown:
SAS-60
™
Sensor Connectors:
Straight Connector (4 contact, DIN 72575) (Schlemmer) part number 9800 351
90 degree Connector (4 contact, DIN 72575) (Schlemmer) part number 9800 331
Contact Pins (Schlemmer) part number 7814 125
YAS-60
™
Wire Harness Connectors:
(Robert Bosch) part number 1 928 404 025
YAS-60
™
Wire Harness Terminals:
(Robert Bosch) part number 1 928 498 001
Brake Demand Sensor/Load Sensor Wire Harness Connectors:
Metri-Pack Connector (Packard) part number 1206 5287
Contact Pins (Packard) part number 1210 3881
