Fault Codes
FIGURE 21 - Reading ABS Configuration Codes
VOLTAGE CONFIGURATIONS
Flashes Description
1 12 Volt System
2 24 Volt System
ABS CONFIGURATIONS
Flashes Description
2 4 Sensors/4 Modulator Valves
3 4 Sensors/3 Modulator Valves
6 6 Sensors/4 Modulator Valves
8 6 Sensors/6 Modulator Valves
9 6 Sensors/5 Modulator Valves
– Select Low Steer
RETARDER CONFIGURATIONS/INTERAXLE
Flashes Engine Interface Retarder Relay Control Interaxle Lock Control
1 (5) NO NO NO (YES)
2 (6) YES NO NO (YES)
3 (7) YESNO NO (YES)
4 (8) YES YES NO (YES)
1st
2nd
3rd
4th
Blink Code
Sequence
1.5 Sec.
Pause
4.5 Sec.
Pause
1.5 Sec.
Pause
Flashes Engine Control Brake Control
2NO NO
3 N/A N/A
4 N/A N/A
5 YES YES
ATC CONFIGURATIONS
