BENDIX GEN 4 GEN 5 ABS User Manual

40
A (18-Way) 1 J1922/J1939 -
2 Gen 4
™
ABS J1939 Shld/Gen 5
™
ABS TIL
3 J1922/J1939 +
4NC
5 Off Road ABS Switch (ORS)
6 ATC Mud & Snow Switch
7 Ignition, Switched
8 V Bat 2
9 V Bat 1
10 Ground - ECU
11 Ground - Diagonal 2
12 Ground - Diagonal 1
13 SAE J1587-
14 SAE J1587+
15 NC, Interlock
16 ATC Light
17 Retarder Relay
18 Indicator Lamp/Diagnostic Switch
B (6-Way) 1 PMV1 (Left Steer), Rel Solenoid
2 PMV1 (Left Steer), Hold Solenoid
3 PMV1 (Left Steer), Common
4 Speed Sensor 2 (Left Steer) +
5 Speed Sensor 2 (Left Steer) -
6 Brake Light Switch
C (9-Way) 1 NC
2NC
3NC
4 Speed Sensor 3 (Right Steer) +
5 Speed Sensor 3 (Right Steer) -
6NC
7 PMV2 (Right Steer), Rel Solenoid
8 PMV2 (Right Steer), Hold Solenoid
9 PMV2 (Right Steer), Common
ECU
CONNECTOR PIN DESCRIPTION
ECU
CONNECTOR PIN DESCRIPTION
D (15-Way) 1 PMV3 (Left Rear), Rel Solenoid
2 PMV3 (Left Rear), Hold Solenoid
3 PMV3 (Left Rear), Common
4 ATC Valve -
5 Speed Sensor 4 (Left Rear) +
6 Speed Sensor 4 (Left Rear) -
7 ATC Valve +
8 Speed Sensor 5 (Right Rear) +
9 Speed Sensor 5 (Right Rear) -
10 PMV4 (Right Rear), Rel Solenoid
11 PMV4 (Right Rear), Hold Solenoid
12 PMV4 (Right Rear), Common
13 NC
14 NC
15 NC
E (12-Way) 1 PMV5 (Left Rear Rear), Rel Solenoid
2 PMV5 (Left Rear Rear), Hold Solenoid
3 PMV5 (Left Rear Rear), Common
4NC
5 Speed Sensor 6 (Left Rear Rear) +
6 Speed Sensor 6 (Left Rear Rear) -
7NC
8 Speed Sensor 7 (Right Rear Rear) +
9 Speed Sensor 7 (Right Rear Rear) -
10 PMV6 (Right Rear Rear), Rel Solenoid
11 PMV6 (Right Rear Rear), Hold Solenoid
12 PMV6 (Right Rear Rear), Common
FIGURE 41 - Cab Mount ECU – Pin Identification Chart
