Diagnostic Trouble Codes (DTCs),
Descriptions and Service Action Codes
Go to the Service Action
Code List in Table 2
(Pages 11-14)
DTC Description
1 High Battery Voltage
B
2 Low Battery Voltage
3-12 Internal Error A
13 Internal Error B
14-16 Internal Error A
17 Internal Error Q
18 J1939 Bus Fault M
19 Calibration not complete
Q
20 Internal Error
21-35 Internal Error A
36 Image Processor software version error I
37-42 Internal Error A
43 Calibration data corrupt Q
44-46 Internal Error A
47 SPC Calibration not complete Q
48-49 Internal Error A
50 Dynamic Calibration out of range
Q
51 Dynamic Calibration not complete
52-57 Internal Error A
58 Internal Error
Q59 Vehicle Calibration not complete
60 Image Processor Calibration error
61 Internal Error A
62 J1939: Vehicle controller message missing - LD
M
63 J1939: Brake controller message missing - VDC2
64 J1939: Engine controller message missing - CCVS1
65 J1939: Vehicle controller message missing - OEL
66 J1939: Vehicle controller signal error - OEL Turn Signal
N
67 J1939: Vehicle controller signal error - LD Right Turn
68 J1939: Vehicle controller signal error - LD Left Turn
69 J1939: Brake controller signal error - VDC2 Steering Wheel
70 J1939: Brake controller signal error - VDC2 Yaw Rate
71 J1939: Brake controller signal error - Lateral Accell
72 Private CAN: Error frame threshold exceeded V
73 J1939: Brake controller signal error - EBC2 Wheel Speed
N
74 J1939: Brake controller signal error - EBC1 Brake Switch
75 J1939: Vehicle controller signal error - LCMD Right Turn
76 J1939: Vehicle controller signal error - LCMD Left Turn
77 Internal Error A
Note: The system will not report newly active J1939 DTCs until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Table 1 – DTC Code to Service Action Code (Pages 8–10)
2.10 TABLE OF DIAGNOSTIC TROUBLE CODES (DTCs) AND SERVICE ACTION CODES
Look in the left column below for the DTC and nd the Service Action Code to follow in Table 2 (Section 2.11).
