4
S-1483 ©2006 Bendix Commercial Vehicle Systems LLC 10/2006 Printed in U.S.A. All Rights Reserved.
2S/1M - DOLLY AXLE
CONTROL
Trailer
Chassis
Harness
Trailer ABS
Pigtail
Harness
5-PIN
CONNECTOR
Ignition
Power
Brake
Light
Power
Ground
7-PIN
CONNECTOR
SUPPLY
LINE
CONTROL
LINE
A Brake
Light Power
B Ignition
Power
C NC
D Warning
Lamp
E Ground
C
E
B
A
D
ABS
Indicator Lamp
TABS
Dolly
Bendix
®
SC-3™ Single
Check Valve
Bendix
®
R-12P™ Pilot
Coupling - Control
Coupling - Supply
Right -
“Curb-Side”
Left -
“Road-Side”
Relay Valve
Bendix
®
TABS6
Trailer
ABS
Module
Bendix WS-24™
Wheel Speed
Sensor "SL"
®
Bendix WS-24™
Wheel Speed
Sensor "SR"
®
Bendix DC-4™
Double Check
Valve
®
Bendix TR-3™
Inversion
Valve
®
Bendix PR-3™
Pressure Protection
Valve
®
Bendix SV-4™
Synchro Valve
®
ABS
FIGURE 5 - TRAILER ABS 2S/1M DOLLY AXLE SYSTEM SCHEMATIC
FIGURE 4 - TRAILER ABS 2S/1M SYSTEM SCHEMATIC
2S/1M - AXLE
CONTROL
Trailer
Chassis
Harness
ABS
Dual Axle Trailer
Bendix
SR-5™ Trailer
Spring Brake
Valve
Trailer ABS
Pigtail
Harness
5-PIN
CONNECTOR
Ignition
Power
Brake
Light
Power
Ground
7-PIN
CONNECTOR
SUPPLY
LINE
CONTROL
LINE
A Brake
Light Power
B Ignition
Power
C NC
D Warning
Lamp
E Ground
C
E
B
A
D
Bendix
®
TABS6
Trailer
ABS
Module
ABS
Indicator Lamp
TABS
Bendix WS-24™
Wheel Speed
Sensor "SR"
Bendix WS-24™
Wheel Speed
Sensor "SL"
Right -
“Curb-Side”
Left -
“Road-Side”
®
®
®
