A-6
Rev 7 Sep/2005
KMD 550/850 Appendix A
Feature Conditions Icon / Colors Other
Characteristics
TOPO on TOPO off
Visual
Reference
Points
Black on
white with
white on
black label
Not displayed Will be enabled or dis-
abled based on Map
Setup page (2) setting.
The label will indicate
the VRP name.
Highlighted when the
icon is designated with
the joystick pointer.
