A-8
Rev 7 Sep/2005
KMD 550/850 Appendix A
Icon Colors Description
Brown on cyan EGPWS with warnings are enabled, being displayed.
Brown on cyan with
yellow “!”
EGPWS with warnings are disabled, being displayed.
Black on gray EGPWS with warnings are enabled, not being dis-
played.
Black on gray with
yellow “!”
EGPWS with warnings are disabled, not being dis-
played.
Black on gray with red
slash
EGPWS data invalid / not being received.
Black on a cyan back-
ground
No FIS data is currently being received but previously
received data is being displayed on the present page.
Black on a cyan back-
ground
FIS data is currently being received from a signal and
displayed on the present page.
Black on gray FIS data is not being received or displayed on the pre-
sent page.
Black on gray FIS data is currently being received from a signal but not
displayed on the present page.
Black on gray with red
slash
Fault with connection or data link radio.
Black on gray FIS graphical METAR overlay is available but not dis-
played.
Black, green, yellow
on cyan
FIS graphical METAR overlay is enabled and displayed.
Black on gray FIS data not being received. FIS graphical METAR
overlay is available but not displayed.
Black, green, yellow
on cyan
FIS data not being received. FIS graphical METAR
overlay is enabled and displayed.
Black on gray with red
slash
VDL radio fault. FIS graphical METAR overlay is avail-
able but not displayed.
Black on gray with red
slash (left icon). Black,
green and yellow on
cyan (right icon).
VDL radio fault. FIS graphical METAR overlay is
enabled and displayed.
