RJW Series of Rolling Jacks 9 P/N 5900093 — Rev. B — October 2020
Specifications
Model
RJ45LP RJ45W
Lifting capacity 4,500 lbs / 2,041kg 4,500 lbs / 2,041 kg
Minimum Drive-Over Height (Pad only) 4.25" / 108 mm 4.5" / 114 mm
Maximum Lifting Height (Pad only) 15.25" / 387 mm 15.5" / 394 mm
Minimum arm reach 42" / 1,067 mm 42" / 1,069 mm
Maximum arm reach 61" / 1,549 mm 57" / 1,449 mm
Maximum operating hydraulic pressure 2, 490 psi 2,490 psi
Shipping weight 306 lbs / 139 kg 380 lbs / 172 kg
Model
RJ6W RJ7W RJ9W
Lifting capacity 6,000 lbs / 2,721 kg 7,000 lbs / 3,175 kg 9,000 lbs / 4,082 kg
Min. Drive-Over Height
(Pad only)
1.25" / 32 mm 4" / 102 mm 5.25" / 133 mm
Max. Lifting Height
(Pad only)
12" / 305 mm 14.75" / 375 mm 16.25" / 413 mm
Minimum arm reach 42" / 1,062 mm 42" / 1,062 mm 42" / 1,062 mm
Maximum arm reach 56" / 1,426 mm 56" / 1,426 mm 56" / 1,426 mm
Maximum operating
hydraulic pressure
3,370 psi 4,550 psi 5,020 psi
Shipping weight 426 lbs / 193 kg 431 lbs / 195 kg 445 lbs / 206 kg
Specifications are subject to change without notice.
About Vehicle Wheelbases
A four-post Lift supports less weight than its rated capacity when the wheelbase of the Vehicle on the
Lift is shorter. This is because the wheels of these shorter wheelbase Vehicles are closer to the middle
of the Runways, where there is less strength. Consequently, the rated capacity of that Lift is less with
these shorter wheelbase Vehicles on the Runways.
For example, if you want to raise a Vehicle with a wheelbase of only 100" on an HDS-14LSX Lift, the
rated capacity of the Lift is reduced by 50% to 7,000 lbs (3,175 kg) for that Vehicle.
Rated capacity information is included in the Specifications section in the manual of all four-post Lifts.
Refer to the manual for a specific Lift for additional information.
This reduced capacity based on Vehicle wheelbase does not impact the rated capacity of the Rolling
Jacks used on those Lifts. Nevertheless, make sure to always check the rated capacity of the Lift your
Rolling Jacks are being used on to make sure it does not exceed the rated capacity of the Lift for the
Vehicle that is on the Lift.
