PARAMETERS, LOGIC AND SPECIAL FUNCTIONS
The tables below describe the individual functions available in the control unit.
PARAMETERS (PAR)
MENU FUNCTION
MIN-MAX-(Default)
MEMO
TCA
Automatic closing time. Active only with logic “TCA”=ON.
At the end of the set time the control unit orders a closing manoeuvre.
1-240-(40s)
TM1
Operating time, motor 1. The operating time is adjusted at normal speed during
motor 1 opening and closing phases. See Paragraph “Adjustment of the gate leaf
speed”.
By setting the value to 0, the operation is performed with around 2 seconds of
pick-up and then the movement is carried on at reduced speed for the entire
stroke. In the motors with encoder, the value is expressed in percentage. In mo-
tors without encoder the value is expressed in seconds.
0-99-(5)
TM2
Operating time, motor 2. The operating time is adjusted at normal speed during
motor 2 opening and closing phases. See Paragraph “Adjustment of the gate leaf
speed”.
By setting the value to 0, the operation is performed with around 2 seconds of
pick-up and then the movement is carried on at reduced speed for the entire
stroke. In the motors with encoder, the value is expressed in percentage. In mo-
tors without encoder the value is expressed in seconds.
0-99-(5)
Tped
Adjusts the motor 1 opening percentage (pedestrian function).
With Encoder equipped motors the value is expressed in a percentage (99% mean
complete opening cycle).
With the motors without Encoder or electrical Limit switch, the value is expressed
in seconds. In the motors with encoder, the value is expressed in percentage. In
motors without encoder the value is expressed in seconds.
1-99 (50)
PMo1
The anti-crash device* (amperometric sensor) operation is adjusted in the open-
ing phase, at normal speed - Motor 1.
1-99-(50%)**
PMC1
The anti-crash device* (amperometric sensor) operation is adjusted in the closing
phase, at normal speed - Motor 1.
1-99-(50%)**
PMo2
The anti-crash device* (amperometric sensor) operation is adjusted in the open-
ing phase, at normal speed - Motor 2.
1-99-(50%)**
PMc2
The anti-crash device* (amperometric sensor) operation is adjusted in the closing
phase, at normal speed - Motor 2.
1-99-(50%)**
TDMo
Mot.2 opening delay time.
Regulates the delay time of motor 2 on opening with respect to motor 1
0-15-(2s)
TDMC
Mot.1 closing delay time
Regulates the delay time of motor 1 on closing with respect to motor 2
0-40-(3s)
TLS
SERL contact activation time (Service light) 29/30 terminals.
At each manoeuvre the contact closes for the set time.
See Figure 4 connection scheme.
1-240-(60s)
TLOc
Electric lock activation time. The value is expressed in 1/10s (0=0s - 50=5s) 0-50 (5=0,5s)
SLD1
Adjusts motor 1 speed during slowing phases.
This value is expressed in percentage.
30-70 (50%)
SLD2
Adjusts motor 2 speed during slowing phases.
This value is expressed in percentage.
30-70 (50%)
SpD1
Adjusts motor 1 speed during normal speed phase.
Value expressed in percentage.
30-99 (99%)
SpD2
Adjusts motor 2 speed during normal speed phase.
Value expressed in percentage.
30-99 (99%)
Pso1
The anti-crash device* (amperometric sensor) operation is adjusted in the open-
ing phase, at reduced speed - Motor 1.
1-99-(20%)**
Psc1
The anti-crash device* (amperometric sensor) operation is adjusted in the closing
phase, at reduced speed - Motor 1.
1-99-(20%)**
Pso2
The anti-crash device* (amperometric sensor) operation is adjusted in the open-
ing phase, at reduced speed - Motor 2.
1-99-(20%)**
Psc2
The anti-crash device* (amperometric sensor) operation is adjusted in the closing
phase, at reduced speed - Motor 2.
1-99-(20%)**
