Page #4 background imageLoading...
Page #4 background image
9
CONTROL PANEL CORE
WIRE DIAGRAM
Wire connections shown in Fig. 1 are described hereunder:
Terminals Function Description
L-N-GND Power supply
Input, 230VAC 50Hz (CORE)
Input, 115VAC 50/60Hz (CORE 115V))
(1-Phase/2-Neutral/GND-Ground connection)
MOT-COM-MOT Motor
Connection to motor:
(MOT-move/COM-Common/MOT-move)
N-BLINK LAMP
Output, connection to Flashing light
CORE: 230 Vac 40W max.
CORE 115V: 115 Vac 40W max.
SWO SWO Input, OPENING limit switch (Normally Closed contact)
SWC SWC Input, CLOSING limit switch (Normally Closed contact)
PHOT (CLOSE) PHOT
Input, connection to safety devices, Normally Closed (N.C.) contact
(e.g. photocells): configurable through DIP3).
In “Service man” mode, it activates the CLOSE function. In this
case connect a Normally Open (N.O.) key.
STOP STOP Input, STOP key (N.C. contact)
COM COM Common, all control inputs.
P.P. (OPEN) Step-by-Step
Input, step-by-step key (N.O. contact).
In “Service man” mode, it activates the OPEN control function.
24 VAC 24Vac Output, 24Vac/200mA max accessory power supply.
SCA SCA
Contact free from voltage, not insulated for the connection of open
gate indicator lamp.
Open contact with closed door leaf. Flashing light during the door
leaf movement. With open door leaf, the contact is closed.
ENC1 ENCODER
Input, connection of the encoder.
See section HOW TO ADJUST BRAKING
SHIELD-ANT Antenna
Connection of the antenna to the incorporated radio-receiver module
(SHIELD-screen/ANT-signal).
Note:
The control unit uses a “P2” key with the same functions of the Step-by-Step push-button. This is useful
to control the automatic system during installation (only with DIP2: OFF).
CHECKING CONNECTIONS:
1) Cut off power supply.
2) Manually release the door, move it at around half stroke and lock it again.
3) Reset power supply.
4) Send the step-by-step (P.P.) control signal through the P2 key, P.P. or remote control.
5) The door leaves should open. If not, with stopped motor, it is sufficient to invert the move wires of the
motor (MOT/MOT) of the motor and the limit switches (SWO/SWC).
6) Adjust Times and operating Logics.
