Trimmer functions
TCA Adjustment of the automatic close time if enabled by Dip-Switch 1.
Adjustment ranges from 1 sec to max 90 sec
AMP-O Adjustment of the amperometric sensor obstacle detection sensitivity during the open
cycle.
AMP-C Adjustment of the amperometric sensor obstacle detection sensitivity during the close
cycle.
Turn the trimmers clockwise (+) to increase the torque, turn them anticlockwise (-) to reduce
the torque.
Adjustment of trimmers AMP-O and AMP-C must comply with statutory regulations.
If an obstacle is detected:
When opening, the gate is stopped.
When closing, the gate stops and opens for about 3 sec.
Dip-Switch functions
DIP 1 “TCA” Enables or disables automatic closing.
Off: automatic closing disabled
On: automatic closing enabled
DIP 2 “COND.” Enables or disables the high trafc function.
Off: High trafc function disabled.
On: High trafc function enabled. The P.P. (Step-by-step) or transmitter signal is
ignored during the open cycle and the TCA cycle (if enabled).
DIP 3 Not used.
DIP 4 “Radio” Enables or disables transmitters with programmable codes
On: Radio receiver enabled exclusively for rolling-code transmitters.
Off: Receiver enabled for both rolling-code and programmable transmitters
(self-learn and dip-switch) .
Motor speed adjustment
CAUTION! This adjustment strongly affects the safety of the gate automation.
Make sure that the gate thrust complies with statutory regulations.
If the gate speed is changed the amperometric sensor must be calibrated accordingly.
Two faston terminals are provided on the transformer:
Faston F1 (white) regulates the door opening and closing speed and can be preset on three voltage
values:
• 20V: (low speed)
• 28V: (medium speed)
• 35V: (high speed)
Faston F2 (red) must not be moved from 20V position.
Conguration with built-in receiver
The control unit is tted with a built-in radio module for receiving remote controls both with xed codes
and variable codes (see dip-switch 4 functions), with a frequency of 433.92MHz.
For a transmitter to be used, the module rst has to self-learn its code. The memorise procedure is
illustrated below, the module can memorise up to 64 different codes.
Memorising a new transmitter by activating the P.P. function
- Press the PGM button once for 1sec and the Power LED will start blinking at 1 sec intervals.
- Press the transmitter button within 10 sec to memorise with the P.P. (Step-by-step) function.
To exit the programming procedure wait 10 sec or press the PGM button for 1 sec.
Remote Learning of a transmitter
If one transmitter has already been memorised others can be memorised without having to access the
control unit as follows:
- Press the hidden key on the memorised transmitter, the courtesy light will start blinking at 1 sec
