CP.BISON OTI CONTROL UNIT
INPUT/OUTPUT FUNCTIONS
CAUTION!: The CP.BISON OTI control unit is equipped with an embedded anti-crash device (amperometric
sensor). Given the overall dimensions of the door leaves for which the device is intended, the latter cannot
be considered a safety device. It is therefore STRICTRLY MANDATORY to install activated protection sen-
sitive edges according to regulations in force.
N° Terminals Function Description
1-2-3-4 Power supply
Single-phase or three-phase mains power supply.
The unit is powered through a mains filter applied before the control unit.
Single-phase 1: Phase - 2: Neutral – 3: Not in use - 4: GND
Three-phase 1:L1 - 2:L2 - 3:L3 - 4:GND.
5-6-7-8 INVERTER
Single-phase or three-phase INVERTER connection
Single-phase 6: Phase – 7: NEUTRAL
Three-phase 5:GND - 6:R - 7:S - 8:T.
9-10 Flashing light Connection of flashing light, 230VAC 40W max, or 115VAC 40W max, for BISON TI 115.
15-16
24V Flashing
light or Phototest
Connection to 24VAC flashing light or Phototest output for checked photocells.
17-18 SCA Normally open, voltage-fee contact for open gate indicator light, 24VAC 0.5A max
19-20 24 VAC Output, power supply of accessories, 24Vac/400mA max
SERIAL 485 Serial, inverter 485 serial communication between control logics and Inverter.
Encoder Encoder Connection to motor Encoder.
21-22 Antenna Connection to built-in radio receiver module of the antenna (21-signal/22-monitor).
23-36 COM Common, for all control inputs.
24 SWC Input, CLOSE limit switch (Normally Closed contact)
25 SWO Input, OPEN limit switch (Normally Closed contact)
26 PHOT 1
Input, Limit switch 1 (NC contact). It can be disconnected in the opening phase, see PH01 logics.
27 PHOT 2
Input, Limit switch 2 (NC contact). It can be disconnected in the opening phase, see PH02 logics.
28 PHOT 3
Input, Limit switch 3 (NC contact). It can be disconnected in the opening phase, see PH03 logics.
29 PHOT 4
Input, Limit switch 4(NC contact). It can be disconnected in the opening phase, see PH04 logics.
30 STOP Input, STOP push-button (Normally Closed contact)
31 OPEN Input, push-button for OPEN contact (Normally Open contact)
32 CLOSE Input, CLOSE push-button (Normally Open contact)
33 PED Input, push-button for pedestrian opening (Normally Open contact)
34 Step-by-Step Input, Step-by-Step push-button (Normally Open contact)
35 AUX IN
Input for Dead man function
By connecting this output to 36-COM terminal, dead man function is enabled.
To be used by means an appropriately marked N.O. contact for controlling the automation
even in case of encoder failure.
35 N/A Not in use
37-38 SAFETY
Input, sensitive safety edge.
When the safety edge is activated, the door movement is stopped
and reversed (see SPIN Parametters).
Safety edge of the resistive type: Jumper “DAS” closed.
Safety edge of the mechanical type: Jumper “DAS” open.
39-40 INVERTER
Safety connection provides control of the hardware emergency stop to the inverter. It is
always open with stopped motor, pressed SAFETY push-button or open motor removable
side in BULL 40 OTL
41-42 COVER
Safety switch, pre-wired to the micro-switch on the removable front side of the automatic
system.
It is activated when the cover is opened. Any operation is blocked.
43-44 SAFETY
Optional safety switch. Connect the self-locking emergency push-button.
Leave terminals short-circuited if not in use.
45-46 AUX-OUT
Auxiliary output, configurable through the AUX parameter.
Voltage-free contact, 250VAC 16A max.
47-48-49
VOLTAGE
SELECTOR
The power supply voltage is selected through a wire jack.
47 and 48 for single-phase power (230VAC).
48 and 49 for three-phase power (400VAC).
In the motors with thermal switch, its activation opens the contact and cuts off the power
supply to the board.
Follow connections shown If the board is removed or replaced.
