11 Getting to know your monitor
Back view
Input and output ports
Available input and output ports may vary depending on your purchased model. Check the
Specification document on the provided CD for details.
1. Input and output ports (vary by
model, see Input and output
ports on page 11)
2. Stand release
3. Cable cover
4. Kensington lock slot
• Above diagram may vary depending on the model.
• Picture may differ from product supplied for your region.
D-SUB
LINE IN
Models with DP inputs 1. AC power input jack
2. DisplayPort socket
3. HDMI socket
4. D-Sub socket
5. Audio Line In
6. Headphone jack
7. DVI-D socket
Models with DVI inputs and speakers
Models with DVI inputs
