6 Getting to know your monitor
2. Getting to know your monitor
Front view
Back view
Above diagram may vary depending on the model.
1. Speakers
2. AC Power Input jack
3. Line In and Line Out
4. Cable clip
5. HDMI socket x 2
6. DVI-D socket
7. D-Sub socket
8. USB port x 1 (upstream; connecting to the
PC)
9. Lock switch
10.USB port x 2 (downstream; connecting to
USB devices)
11.Headphone jack
12.USB port x 2 (downstream; connecting to
USB devices)
13.Headphone hook indicators (two inverted
triangles)
14.Control buttons
15.Power button
E2420HD
3 5 8
13
11
10
1 162 794
12
5
12
14
15
