22 How to adjust the monitor
How to adjust the monitor
This topic describes how to adjust your BenQ LCD monitor using the push button (keys) on the
monitor’s edge, to access the monitor properties using the On-Screen Display (OSD).
1. Power button: Toggles the power ON or OFF.
2. Enter key: Activates the OSD, sub menus, select items, and confirms selection.
3. t(Up) key: For up/increasing adjustment. The Up key is also the hot key for Brightness
setting.
4. u(Down) key: For down/decreasing adjustment. The Down key is also the hot key for
Contrast setting.
5. Exit key: Exits the current menu selection and returns to the previous menu or exits OSD.
The Exit key is also the hot key for Input settings.
6.
i
key : Adjusts vertical position, phase, horizontal position and pixel clock automatically.
1
1
To Next Page
